The Control Valve 3-Way H3F by Clorius Controls is designed for managing the flow of hot oil, water, and other liquids in industrial processes, district or central heating systems, and marine installations. It can function as either a mixing or diverting valve. Available in sizes DN20 to DN65, the valve is constructed from durable cast steel with stainless steel components, ensuring reliability under a nominal pressure of PN40. It features flanges compliant with EN 1092-1 - DIN 2635 standards, making it suitable for various piping systems.
Standard (Options)
  • DIN
Connection (Options)
  • Flanged
Material (Options)
  • Cast Steel
Pressure Rating (Options)
  • PN 40
Flow (Options)
  • Diverting
  • Mixing

Datasheet and documents

Description

Applications

Control valves type H3F are designed for control of hot oil, water and other liquids and can be installed in pipe systems as mixing or diverting valves. The valves are used in conjunction with our temperature regulators for controlling industrial processes, district or central heating plants or marine installations.

GENERALLY

Sizes: DN20, 25, 32, 40, 50, 65

Nom. pressure: PN40

Material: Cast Steel

Material (components): Stainless steel

Flanges: EN 1092-1 - DIN 2635
