Control valve 2-way DN 65-150mm - Gun Metal | Clorius Controls
Control valve 2-way DN 65-150mm - Gun Metal | Clorius Controls

Control valve 2-way DN 65-150mm - Gun Metal | Clorius Controls

The Control Valve 2-way DN 65-150mm by Clorius Controls is a versatile and durable valve made from gun metal, designed for efficient flow regulation in various applications. It is suitable for use with compressed air, cooling systems, demi water, heating, solar energy, and steam. This valve is ideal for industries requiring reliable control in medium to large-scale systems.
Standard (Options)
  • DIN
Connection (Options)
  • Flanged
Material (Options)
  • Gun metal
Pressure Rating (Options)
  • PN 10
Flow (Options)
  • Straight Way

Datasheet and documents

Description

Applications

  • compressed air
  • cooling
  • demi Water
  • heating
  • solar energy
  • steam

Art. No.

Description

Size

Item weight

PN

Type of connection

1-2120189VALVE L2F DN65, EN FLANGESDN6527.0 KGMPN 10Flange
1-2120199VALVE L2F DN80, EN FLANGESDN8036.0 KGMPN 10Flange
1-2120209VALVE L2F DN100, EN FLANGESDN10062.0 KGMPN 10Flange
1-2120219VALVE L2F DN125, EN FLANGESDN125102.0 KGMPN 10Flange
1-2120229VALVE L2F DN150, EN FLANGESDN150145.0 KGMPN 10Flange

Art. No.

Size

d

L

H1

H

1-2120189DN652 1/2" (DN65)240.0120.0175.0
1-2120199DN803" (DN80)260.0125.0185.0
1-2120209DN1004" (DN100)350.0145.0195.0
1-2120219DN1255" (DN125)400.0180.0245.0
1-2120229DN1506" (DN150)480.0280.0

Characteristics

Manufacturer5705737000006
