Control valve 2-way DN 15-32mm - Gun Metal | Clorius Controls
Control valve 2-way DN 15-32mm - Gun Metal | Clorius Controls

Control valve 2-way DN 15-32mm - Gun Metal | Clorius Controls

The Control Valve 2-way DN 15-32mm by Clorius Controls is a versatile and durable valve made from gun metal, designed for efficient flow regulation in various applications. It is suitable for use with compressed air, cooling systems, demi water, heating, solar energy, and steam. This valve is ideal for industries requiring reliable control solutions across a range of fluid types and temperatures.
Standard (Options)
  • DIN
Connection (Options)
  • BSP
  • NPT
Material (Options)
  • Gun metal
Pressure Rating (Options)
  • PN 16
Flow (Options)
  • Straight Way

Datasheet and documents

Description

Applications

  • compressed air
  • cooling
  • demi Water
  • heating
  • solar energy
  • steam

Art. No.

Description

Size

Item weight

PN

Type of connection

1-2110562VALVE L1SB DN20, BSP THREADINGDN201.3 KGMPN 16Rp - female thread cylindrical (BSPT)
1-2110564VALVE L1SB DN20 FOR SALT WATER,NPT113.0 KGMPN 16R - male thread gas conical (BSPT)
1-2111345VALVE L1SB DN15, BSP THREADINGDN151.0 KGMPN 16Rp - female thread cylindrical (BSPT)
1-2111347VALVE L1SB DN15 FOR SALT WATER,NPT5.0 KGMPN 16FPT - female thread conical (NPT)
1-2111357VALVE L1SB DN25, BSP THREADINGDN251.6 KGMPN 16Rp - female thread cylindrical (BSPT)
1-2111358VALVE L1SB DN25 FOR SALT WATER,NPT16.0 KGMPN 16FPT - female thread conical (NPT)
1-2111370VALVE L1SB DN32, BSP THREADINGDN322.9 KGMPN 16Rp - female thread cylindrical (BSPT)
1-2111372VALVE L1SB DN32 FOR SALT WATER,NPT28.0 KGMPN 16FPT - female thread conical (NPT)
1-2119020VALVE L1SB DN25+V4.05+SENSOR POCKET45.0 KGMPN 16R - male thread gas conical (BSPT)

Art. No.

Size

d

L

H1

H

1-2110562DN203/4" (DN20)95.046.079.0
1-21105643/4" (DN20)
1-2111345DN151/2" (DN15)85.040.071.0
1-21113471/2" (DN15)
1-2111357DN251" (DN25)105.050.079.0
1-21113581" (DN25)
1-2111370DN321 1/4" (DN32)64.081.0
1-21113721 1/4" (DN32)
1-21190201" (DN25)

Characteristics

Manufacturer5705737000006
