    KITO® detonation flame arresters

    If potentially explosive gas-air mixtures ignite in a section of pipeline, a deflagration can turn into a detonation under certain instances.

    Standard (Options)
    • DIN
    Connection (Options)
    • Flanged
    Material (Options)
    • 1.4571
    • Steel
    Pressure Rating (Options)
    • PN 10
    • PN 16
    • PN 40

    Datasheet and documents

    Description

    KITO® FL/EO-…-IIB3 (wf)

    -maintenance-friendly and easy to clean design-

    • As inline armature, detonation-proof and flameproof, used for installation in filling pipes outside from tanks in which inflammable liquids are stored.
    • Tested and approved as detonation flame arrester type 4.
    • Approved for all materials of the explosion group IIA1 to IIB3 with MESG ≥ 0.65 mm and an maximum operating temperature of 60 °C.
    • It is only allowed to install pipes of nominal widths ≤ than the nominal widths of the flange.
    • Mounting position is perpendicular.
    • The body of the housing has to be permanently filled with the storage liquid up to the height of the connecting flanges.
    • Equipped with a hexagon head pipe plug for emptying the liquid.
