    KITO® deflagration flame arrester

    If potentially explosive gas-air mixtures ignite in a section of pipeline, the explosion starts out as a deflagration propagating at relatively low pressures and flame speed below speed of sound.

    Standard (Options)
    • DIN
    Connection (Options)
    • Flanged
    Material (Options)
    • 1.4571
    • Steel
    Pressure Rating (Options)
    • PN 40

    Datasheet and documents

    Description

    KITO® RG-Det4-IIA-…-4.5

    KITO® RG-Det4-IIA-…-4.5-T (-TT)

    – design with flange connection-

    • For installation into pipes to the protection of vessels and components against stable detonation of flammable liquids and gases.
    • Tested and approved as detonation flame arrester type 4.
    • Approved for all substances of explosion groups IIA1 to IIA with a maximum experimental safe gap (MESG) > 0.9 mm.
    • Bi-directionally working in pipes, whereby an operating pressure of 4.5 bar abs. and an operating temperature of 60 °C must not be exceeded.
    • All sizes are tested against “stabilized burning” and withstand this up to a max. burn time BT ≤ 1.0 min.
    • To detect a “stabilized burning” a temperature sensor must be installed at each endangered side.
    • Mounting is acceptable in any position, in horizontal as well as in vertical pipes.
