    KITO® detonation flame arresters

    If potentially explosive gas-air mixtures ignite in a section of pipeline, a deflagration can turn into a detonation under certain instances.

    Standard (Options)
    • DIN
    Connection (Options)
    • Flanged
    Material (Options)
    • 1.0619
    • 1.4408
    Pressure Rating (Options)
    • PN 10
    • PN 16

    Datasheet and documents

    Description

    KITO® EFA-Det4-IIA-…/…-3.0-X12

    KITO® EFA-Det4-IIA-…/…-3.0-X12-T (-TT)

    • For installation into pipes to the protection of vessels and components against stable detonation of flammable liquids and gases.
    • Tested and approved as detonation flame arrester type 4.
    • Approved for all substances of explosion groups IIA1 to IIA with a maximum experimental safe gap (MESG) > 0.9 mm.
    • Bi-directionally working in pipes, whereby an operating pressure of 3.0 bar abs. and an operating temperature of 120 °C must not be exceeded.
    • The installation of the detonation flame arrester into horizontal and vertical pipes is permissible.
    • Provided with one or two temperature sensors (PT 100) the armature is certified against short time burning from one or both sides.
    • If only one thermal sensor is attached, it must be installed into that part of the body from which a fire is expected.
