The Control Valve 3-way L3S - DN15-50 by Clorius Controls is designed for regulating various types of water and lubricating liquids. It is suitable for use in control systems for cooling and heating applications across domestic, district heating, industrial, and marine settings. The valve is available in sizes ranging from DN15 to DN50 and is constructed from durable gun metal, ensuring reliability and longevity. It operates under a nominal pressure of PN10 and features ISO 7/1 threading for easy integration into existing systems.
Standard (Options)
  • DIN
Connection (Options)
  • BSP
Material (Options)
  • Gun metal
Pressure Rating (Options)
  • PN 10
Flow (Options)
  • Diverting
  • Mixing

Datasheet and documents

Description

Applications

Control valves type L3S are designed for regulating fresh water, cold and hot sea-water and lubricating liquids. The valves are used in conjunction with temperature regulators in control systems for cooling and heating of domestic premises, district heating, industrial processes or marine installations.

GENERALLY

Sizes:DN15, 20, 25, 32, 40, 50

Nom. pressure: PN10

Material:Gun metal

Material (components):Gun metal

Threads ISO 7/1
