Control Valve 3-Way H3F - DN80-150 | Clorius Controls
Control Valve 3-Way H3F - DN80-150 | Clorius Controls

Control Valve 3-Way H3F - DN80-150 | Clorius Controls

The Control Valve 3-Way H3F by Clorius Controls is designed for regulating hot water, lubricating oil, and other liquid media. It can function as either a mixing or diverting valve within a piping system. Ideal for industrial processes, district and central heating plants, and marine installations, this valve is compatible with temperature regulators. Available in sizes DN80, 100, 125, and 150, it features a nominal pressure of PN16 and is constructed from durable cast steel with components made of aluminum bronze and stainless steel. The valve is equipped with flanges conforming to EN 1092-2, ANSI B16.5 Class 150, and DIN 2633 standards.
Standard (Options)
  • DIN
Connection (Options)
  • Flanged
Material (Options)
  • Cast Steel
Pressure Rating (Options)
  • PN 16
Flow (Options)
  • Diverting
  • Mixing

Datasheet and documents

Description

Applications

Control valves type H3F are designed for regulating of hot water, lubricating oil and other liquid media and can be mounted in the pipe system as either mixing or diverting valves. The valves are used in conjunction with our temperature regulators for controlling industrial processes, district and central heating plants and marine installations.

GENERALLY

Sizes: DN80, 100, 125, 150

Nom. pressure: PN16

Material: Cast steel

Material (components): Alu. bronze & Stainless steel

Flanges: EN 1092-2 ANSI B16.5 Class 150 DIN 2633
