Control valve balanced 2-way DN 15-80mm - Nodular Cast Iron | Clorius Controls
Control valve balanced 2-way DN 15-80mm - Nodular Cast Iron | Clorius Controls

Control valve balanced 2-way DN 15-80mm - Nodular Cast Iron | Clorius Controls

The Control Valve Balanced 2-Way DN 15-80mm by Clorius Controls is a versatile and durable valve made from nodular cast iron, designed for efficient flow regulation in various applications. It is suitable for use with compressed air, cooling systems, demineralized water, heating systems, solar energy setups, and steam applications. This valve ensures reliable performance and precise control across a range of industrial and commercial environments.
Standard (Options)
  • DIN
  • ANSI
  • JIS
Connection (Options)
  • Flanged
Material (Options)
  • EN-GJS-400-15 (Nodular Cast Iron)
Pressure Rating (Options)
  • PN 25
Flow (Options)
  • Straight Way

Datasheet and documents

Description

Applications

  • compressed air
  • cooling
  • demi Water
  • heating
  • solar energy
  • steam

Art. No.

Description

Size

Item weight

PN

Type of connection

1-2312503VALVE H1FBN DN15, JIS 5KDN154.0 KGM5KJIS flange
1-2411400VALVE G1FBN DN15, EN FLANGESDN154.0 KGMPN 25Flange
1-2411401VALVE G1FBN DN15, JIS 16KDN154.0 KGM10KJIS flange
1-2411402VALVE G1FBN DN15, ANSI 150DN154.0 KGMClass 150ANSI flange
1-2411403VALVE G1FBN DN15, JIS 5KDN154.0 KGM5KJIS flange
1-2411404VALVE G1FBN DN15, JIS 16KDN154.0 KGM16KJIS flange
1-2411410VALVE G1FBN DN20, EN FLANGESDN205.0 KGMPN 25Flange
1-2411411VALVE G1FBN DN20, JIS 10KDN205.0 KGM10KJIS flange
1-2411412VALVE G1FBN DN20, ANSI 150DN205.0 KGMPN 25ANSI flange
1-2411413VALVE G1FBN DN20, JIS 5KDN205.0 KGM5KJIS flange
1-2411414VALVE G1FBN DN20, JIS 16KDN205.0 KGM16KJIS flange
1-2411420VALVE G1FBN DN25, EN FLANGESDN256.0 KGMPN 25Flange
1-2411420CVALVE G1FBN DN25, CUT THROUGH5.0 KGMPN 25
1-2411421VALVE G1FBN DN25, JIS 10KDN256.0 KGM10KJIS flange
1-2411422VALVE G1FBN DN25, ANSI 150DN256.0 KGMClass 150ANSI flange
1-2411423VALVE G1FBN DN25, JIS 5KDN256.0 KGM5KJIS flange
1-2411424VALVE G1FBN DN25, JIS 16KDN256.0 KGM16KJIS flange
1-2411430VALVE G1FBN DN32, EN FLANGESDN329.0 KGMPN 25Flange
1-2411432VALVE G1FBN DN32, ANSI 150DN3227.0 KGMClass 150ANSI flange
1-2411433VALVE G1FBN DN32, JIS 5KDN329.0 KGM5KJIS flange
1-2411434VALVE G1FBN DN32, JIS 16KDN329.0 KGM16KJIS flange
1-2411440VALVE G1FBN DN40, EN FLANGESDN4013.0 KGMPN 25Flange
1-2411450VALVE G1FBN DN50, EN FLANGESDN5016.0 KGMPN 25Flange
1-2411451VALVE G1FBN DN50 WITH STRONG SPRRING16.0 KGMPN 25Flange
1-2411454VALVE G1FBN DN50, JIS 5KDN5016.0 KGM5KJIS flange
1-2411455VALVE G1FBN DN50, JIS 10KDN5016.0 KGM10KJIS flange
1-2411457VALVE G1FBN DN50, JIS 16KDN5016.0 KGM16KJIS flange
1-2411460VALVE G1FBN DN65, EN FLANGESDN6523.0 KGMPN 25Flange
1-2411470VALVE G1FBN DN80, EN FLANGESDN8038.0 KGMPN 25Flange
1-2411471VALVE G1FBN DN80 JIS 10KDN8038.0 KGM10KJIS flange
1-2411472VALVE G1FBN DN80, ANSI 150DN8038.0 KGMClass 150ANSI flange
1-2411473VALVE G1FBN DN80, JIS 5KDN8038.0 KGM5KJIS flange
1-2411474VALVE G1FBN DN80, JIS 16KDN8038.0 KGM16KJIS flange
1-2411540VALVE G1FBN DN40, ANSI 150DN4013.0 KGMClass 150ANSI flange
1-2411541VALVE G1FBN DN40, JIS 10KDN4013.0 KGM10KJIS flange
1-2411542VALVE G1FBN DN40, JIS 5KDN4013.0 KGM5KJIS flange
1-2411543VALVE G1FBN DN40, JIS 16KDN4013.0 KGM16KJIS flange
1-2411550VALVE G1FBN DN50, ANSI 150DN5016.0 KGMClass 150ANSI flange
1-2411560VALVE G1FBN DN65, ANSI 150DN6523.0 KGMClass 150ANSI flange
1-2411561VALVE G1FBN DN65, JIS 10KDN6523.0 KGM10KJIS flange
1-2411562VALVE G1FBN DN65, JIS 5KDN6523.0 KGM5KJIS flange
1-2411563VALVE G1FBN DN65, JIS 16KDN6523.0 KGM16KJIS flange
1-4211431VALVE G1FBN DN32, JIS 10KDN329.0 KGM10KJIS flange

rt. No.

Size

d

L

H1

H

1-2312503DN151/2" (DN15)130.080.0101.0
1-2411400DN151/2" (DN15)130.080.0101.0
1-2411401DN151/2" (DN15)130.080.0101.0
1-2411402DN151/2" (DN15)130.080.0101.0
1-2411403DN151/2" (DN15)130.080.0101.0
1-2411404DN151/2" (DN15)130.080.0101.0
1-2411410DN203/4" (DN20)150.085.0107.0
1-2411411DN203/4" (DN20)150.085.0107.0
1-2411412DN20DN20150.085.0107.0
1-2411413DN203/4" (DN20)150.085.0107.0
1-2411414DN203/4" (DN20)150.085.0107.0
1-2411420DN251" (DN25)160.070.0112.0
1-2411420CDN25
1-2411421DN251" (DN25)160.070.0112.0
1-2411422DN251" (DN25)160.070.0112.0
1-2411423DN251" (DN25)160.070.0112.0
1-2411424DN251" (DN25)160.070.0112.0
1-2411430DN321 1/4" (DN32)180.075.0122.0
1-2411432DN321 1/4" (DN32)180.075.0122.0
1-2411433DN321 1/4" (DN32)180.075.0122.0
1-2411434DN321 1/4" (DN32)180.075.0122.0
1-2411440DN401 1/2" (DN40)200.085.0125.0
1-2411450DN502" (DN50)230.095.0140.0
1-24114512" (DN50)
1-2411454DN502" (DN50)230.095.0140.0
1-2411455DN502" (DN50)230.095.0140.0
1-2411457DN502" (DN50)230.095.0140.0
1-2411460DN652 1/2" (DN65)290.0110.0154.0
1-2411470DN803" (DN80)310.0115.0164.0
1-2411471DN803" (DN80)310.0115.0164.0
1-2411472DN803" (DN80)310.0115.0164.0
1-2411473DN803" (DN80)310.0115.0164.0
1-2411474DN803" (DN80)310.0115.0164.0
1-2411540DN401 1/2" (DN40)200.085.0125.0
1-2411541DN401 1/2" (DN40)200.085.0125.0
1-2411542DN401 1/2" (DN40)200.085.0125.0
1-2411543DN401 1/2" (DN40)200.085.0125.0
1-2411550DN502" (DN50)230.095.0140.0
1-2411560DN652 1/2" (DN65)290.0110.0154.0
1-2411561DN652 1/2" (DN65)290.0110.0154.0
1-2411562DN652 1/2" (DN65)290.0110.0154.0
1-2411563DN652 1/2" (DN65)290.0110.0154.0
1-4211431DN321 1/4" (DN32)180.075.0122.0

Characteristics

Manufacturer5705737000006
