    The Control Valve 2-way DN 65-150mm Reverse Acting by Clorius Controls is designed for cooling applications and is constructed from durable gun metal. This versatile valve is suitable for a range of applications, including compressed air, cooling, demi water, heating, solar energy, and steam systems. Its reverse acting mechanism ensures precise control and reliability in various industrial and commercial settings.
    Standard (Options)
    • DIN
    Connection (Options)
    • Flanged
    Material (Options)
    • Gun metal
    Pressure Rating (Options)
    • PN 10
    • PN 16
    Flow (Options)
    • Straight Way

    Datasheet and documents

    Description

    Applications

    • compressed air
    • cooling
    • demi Water
    • heating
    • solar energy
    • steam

    Art. No.

    Description

    Size

    Item weight

    PN

    Type of connection

    1-2120190VALVE L2FR DN65, EN FLANGESDN6527.0 KGMPN 10Flange
    1-2120200VALVE L2FR DN80, EN FLANGESDN8036.0 KGMPN 10Flange
    1-2120210VALVE L2FR DN100, EN FLANGESDN10062.0 KGMPN 10Flange
    1-2120220VALVE L2FR DN125, EN FLANGESDN125102.0 KGMPN 10Flange
    1-2120230VALVE L2FR DN150, EN FLANGESDN150145.0 KGMPN 10Flange
    1-2120850VALVE L2FR DN8035.0 KGMPN 16Flange

    Art. No.

    Size

    d

    L

    H1

    H

    1-2120190DN652 1/2" (DN65)240.0120.0175.0
    1-2120200DN803" (DN80)260.0125.0185.0
    1-2120210DN1004" (DN100)350.0145.0195.0
    1-2120220DN1255" (DN125)400.0180.0245.0
    1-2120230DN1506" (DN150)480.0189.0280.0
    1-21208503" (DN80)

    Characteristics

    Manufacturer5705737000006
